High Quality Durable Control Innovation Factory Outlet Hot Sale Multi-Function Check Valve

The shuttle valve is equivalent to two check valve combination valve , and its role is equivalent to"OR gate".There are 3 waysvalves , which detect the higher pressure signal between 2input signal.

Model:
【P54】RHV-M-Check Valve
Brand:
WEISENBL

Quantity:
Availability:





Inquire Add to Basket

Check Valve Relief Valves Hydraulic Lock Flow Control Valve Control valve Overcenter Control Valve Pressure Control Valve Proportional Valve Directional Control Valve Flow Valve

Product Description

Stainless Steel Threaded End High Pressure Ball Valve Check Valve 3/8Inch

Stainless Steel Solenoid Valve body / Stainless Steel Non-Standard Machining Parts

1.Samples Delivery Time

Two days - our existing samples

10-15 days - If new sample development

2.Shipment Delivery Time: 25-35 days after confirming the order

3.Production Capacity :300000 pcs each month,

4.Packing Details : put the fittings layer by layer in master carton

5.Testing : Material Testing ,Hardness Testing ,Key Dimention Testing,Gauge Testing

6.Inspection: Each cargo will be inspected before shipping. The third-party inspection company is acceptable.

Series	D1	T1	DN	D3	L1	L2	L3	L4	S1	S2	S3	Weight(g)	(bar) Working, pressure CF 71
L	06	G1/8A	4.0	14	34.5	27.5	8	42.0	17	17	14	44	400	250
	08	G1/4A	4.0	19	36.5	29.0	12	43.0	19	19	17	59	400	250
	10	G 1/4A	7.0	19	45.5	38.5	12	53.0	22	24	19	125	400	250
	12	G3/8A	9.5	22	47.5	40.5	12	55.0	27	30	22	161	400	250
	15	G1/2A	11.5	27	50.5	43.0	12	57.5	30	32	27	186	400	250
	18	G1/2A	14.0	27	56.0	48.5	14	64.0	36	36	32	275	400	160
	22	G3/4A	18.0	32	63.5	56.0	16	72.0	41	46	36	463	250	1 60
	28	G1A	23.0	40	73.5	66.0	18	82.0	50	55	41	721	250	100
	35	G11/4A	29.0	50	81.0	70.5	20	91.5	60	65	50	1073	250	100
	42	G11/2A	29.0	55	82.0	71.0	22	93.0	65	70	60	1602	250	100
S	06	G1/4A	4.0	19	38.5	31.5	12	46.0	19	19	17	71	420	400
	08	G1/4A	4.0	19	38.5	31.5	12	46,0	19	19	19	74	420	400
	10	G 3/8A	7.0	22	47.5	40.0	12	56.0	24	27	22	128	420	400
	12	G3/8A	7.0	22	47.5	40.0	12	56.0	24	27	24	152	420	400
	14	G1/2A	9.5	27	52.5	44.5	14	62.5	27	32	27	223	420	315
	16	G 1/2A	11.5	27	56.0	47.5	14	65.0	32	36	30	275	420	315
	20	G3/4A	15.0	32	61.0	50.5	16	71.5	41	46	36	490	420	250
	25	G1A	19.0	40	67.5	55.5	18	79.5	46	50	46	647	420	250
	30	G11/4A	24.0	50	77.5	64.0	20	90.5	55	60	50	1180	250	250
	38	G11/2A	29.0	55	88.0	72.0	22	102.0	65	70	60	1670	250	250
